Analog Way Tetra VIO Image Convertor TVC 401

375,00

Artikelnummer: AFSANWTVC401 Categorieën: , ,

Beschrijving

Tetra-VIO™ by Analog Way is a highly versatile A/V Switcher / Converter / Interface with 3 universal Inputs and 1 SD/HD-SDI Input. It accepts a large range of formats, from Computer to Video and HDTV, in Analog or Digital format, and provides a large range of connectors: BNC, HD15, DVI, mini DIN4, Cinch, RCA. The output provides the same diversity of formats, and the same type of signals and connectors.
The Universal A/V Computer and HD Solution in Image Cross Conversion with Digital Audio De/Embedder
Quick overview:
Improves the quality of any video signal
Easy to use menus
Provides Audio/Stereo switching following the video input
Increases Video Image sharpness and brightness
Ideal device for conference room installations
Inputs
3 Universal Inputs + 1 HD/SD-SDI
Converts Virtually any High Resolution up to 2K, TV and HDTV Signals, Analog or Digital (Input/Output)
Computer : RGB, DVI up to 1600×1200 & 2048×1080
NTSC, PAL, SECAM, S.Video, RGB, YUV
HDTV (HD-YUV, HD-RGB)
SDI / HD-SDI
Universal connector Interface & Loop through on each input
Outputs
Computer: RGB, DVI up to WUXGA & 2K
NTSC, PAL, Composite, S. Video, RGB, YUV
HDTV (HD-YUV, HD-RGB)
SDI, HD-SDI
Effects and Features
Stereo Audio:
– 4 inputs with level trim / 1 output
– Embedded Audio Digital & SPDIF
Genlock:
– Multi-format Analog Genlock
– Black Burst PAL, NTSC
– Analog HD Black
2 still logos with settable transparency recorded by acquisition or transfer
Zoom up to 1000%
The image can be positioned up to 100% anywhere off the screen, vertically, horizontally and outside the screen
Image size adjustable to fit any LED wall/tiles.
8 Preset memories
1 Full Frame or 2 logos
Cross hatch dynamic Pattern
Control RGB Tiles Pattern
LED Wall Specific Menu
Supplied with
1 x DVI-I/HD15 adaptor
1 x HD15 to 5BNC adaptor cable
1 x Power cable
1 x Remote control software
